15T Ohm Insulation Resistance Test Set Anti Interference

Name: 15T Ohm Insulation Resistance Test Set Anti Interference
Brand: HNMC
SKU: MCRT005
Rating: 4.9 (200 reviews)

Large Image : 15T Ohm Insulation Resistance Test Set Anti Interference

Product Details:

Place of Origin:	China
Brand Name:	HNMC
Model Number:	MCRT005

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiable
Packaging Details:	Carton package
Delivery Time:	20-25 Days
Supply Ability:	25 pcs per month

Contact Now

Detailed Product Description

Display:	LCD	Voltage Range:	Up To 5KV
Test Range:	0.1M ~ 15TΩ	Power Supply:	180-270V AC
Application:	Worksite, Lab	Short Circuit Current:	≧5mA
Highlight:	5KV Insulation Resistance Test Set , 15T ohm Insulation Resistance Test Set , worksite dielectric resistance test

Insulation Dielectric Test -Insulation Resistance Tester 5kV MCRT005

Main Features

1. 32-bit micro-controller, English interface, easy to operate.

2. Automatically calculates the absorption ratio and the polarization index, and automatically save 15 seconds,

1 minute, 2 minutes,10 minutes to facilitate analysis of data per minute.

3. Output current and short-circuit current are greater than 5mA.Anti-interference ability, which meets

the EHV substation on-site operation.

4. With a fully enclosed high-voltage generator module technology,and the protection of the internal

resistance is safe and reliable.

5. Automatic discharge after testing and real-time monitoring the discharge process

Technical Parameter

Item	Technical Index
Accuracy	± 10%
Range	0.1M ~ 15TΩ
Test Voltage	0.5KV,1KV,2.5KV,5KV
Short Circuit Current	≧5mA
Measuring Time	1 minute to 10 minutes
Power Supply	180 ~ 270VAC, 50Hz/60Hz ± 1%
Working Environment	-10～40℃
Humidity	20～80％

Packing List

No.	Item	Qty
1	Main device	1
2	Red test cable	1
3	Test cable	1
4	Power cord`	1
5	Ground cable	1

After sales service

Our sales and technical team can guarantee a fast and highly efficient after sales service for our products sold.
Once problem happens in clients, firstly we will consider online support of our clients to solve it quickly; secondly we will consider to provide spare parts for client to replace after fixing reason.

We will provide best service to support your marketing field.
