Zhengzhou Great Electric Co.,Ltd.
Home ProductsPortable Meter Test Equipment

3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM

China Zhengzhou Great Electric Co.,Ltd. certification
I'm Online Chat Now

3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM

3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM
3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM

Large Image :  3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM

Product Details:
Place of Origin: China
Brand Name: HNMC
Model Number: MCSP01
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton package
Delivery Time: 15-30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 sets per month
Detailed Product Description
Accuracy: 0.2, 0.5 Current Range: 10-300A (clamp Mode,optional)
Voltage Range: 80-288V GPS/GPRS: Available For Option
Application: Filed Testing Functions: Meter Error, Dial Test....etc
High Light:

3.5" LCD Portable Meter Test Equipment

,

GPS Portable Meter Test Equipment

,

RSM Portable Meter Test Equipment



Portable Single Phase Reference Standard Meter MCSP01



1) 3.5" LCD display

2) Accuracy class: 0.2 or 0.5 (clamp mode)

3) Measuring range: 80V-288V/clamp 10A, 50A, 60A, 100A, 300A optional

4) Power & Energy test, Demand test, Error test, Dial test

5) RS232 communication with PC to upload the test data

6) GPS/GPRS module (optional)

7) DLMS reading (optional)



Technical Index

Current Measurement
Range clamp on CT: 10A, 50A, 60A, 100A, 300A, etc… optional
Accuracy 0.2 or 0.5 class
Voltage measurement
Range 80-312V
Accuracy 0.2
Frequency measurement
Range 45-65HZ
Error ≤ 0.02HZ
Phase angle measurement
Range 0-360 deg.
Error ≤0.1 deg.
Other parameters
Power supply 240V±30%
Power Consumption less than 2VA in current circuit and less than 8VA in voltage circuit



3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM 0

3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM 1

3.5" LCD Display Portable Meter Test Equipment GPS Module Single Phase RSM 2









Function Menu Interface:

1) Meter Parameter Setting   2) Error Test     3) THD  4) Data Save & Inquiry

5) System setting  6) CT ratio test  7) Demand test  8) Dial test   9) others
