Name: 20mA Energy Meter Testing Equipment , ZnO Surge Arrester Tester
Brand: HNMC
SKU: MCZA 6820
Rating: 4.9 (145 reviews)

Product Details:

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	wooden package
Delivery Time:	4-8weeks
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	50 sets per month

Contact Now

Detailed Product Description

Application:

Worksite, Online

Test Range:

0-20mA

Power Supply:

220V+/-10% And Rechargeable Battery

Harmonic Order:

3, 5, 7

High Light:

20mA Energy Meter Testing Equipment

ZnO Surge Arrester On-line Tester MCZA 6820

Function & Character

LCD display
High accuracy sampling, processing, Advanced Fourier harmonic analysis, Reliable data
Directly collecting signal of voltage and current.
3,5,7 times harmonic test, harmonic wave
With resistive current basic wave peak output function
Having inbuilt memory, abble to store 50 groups test records
With USB Port
With preventing wrong connection function
With wireless transmit, acquisition
Inbuilt high accurate o’clock
With high speed thermal printer for testing result printing at workste
With rechargeable battery as power supply

Technical Index

1.voltage and current parameter :

Test item	Test range		Test accuracy
Full current	0-20mA		±(readingX5%＋5µA)
Resistive current	0-20mA		±(readingX5%＋5µA)
Capacitive current	0-20mA		±(readingX5%＋5µA)
Current harmonic	0-20mA		±(readingX10%＋10µA)
Reference voltage	Max.100V RMS		±(readingX5%＋0.5V)
Voltage harmonic	Max.100V RMS		±(readingX10%)
transmitting distance		apparent 500m
Power supply		AC220V±10%, 50HZ / Rechargeable Battery (can continuously work for 6 hour or more after 3-hour charging
Dimension		320260135mm
work temperature		-10℃-40℃
Relative humidity		≤85% non condensing
Storage temperature		-20℃-50℃
Weight		approx 5.0KG

Packing list
